High-strength steel
for critical loads
High-strength fine-grained steel Dillinger, quenched and tempered (Q&T). Yield strength up to 1100 MPa, thicknesses up to 290 mm. Ideal solution for slimmer structures with the highest loads. Direct deliveries to Ukraine from HARD STEEL INDUSTRY.
EN 10025-6
Q&T certified
DILLIMAX MEETS WORLD STANDARDS FOR HIGH-Q&T STEELS
8 reasons to choose high-strength steel
Dillinger
The highest mechanical loads require a material that makes no compromises.
DILLIMAX combines extreme strength, toughness and processability
- the basis of the safest and most economical structures in the world.
Yield strength
up to 1100 MPa
The highest yield strength in its class allows for the design of thin and lightweight load-bearing structures without loss of strength. Less weight = greater material savings.
Thicknesses
from 6 to 290 mm
The widest range of thicknesses in the segment: from 6 mm for mechanical engineering to 290 mm for offshore structures. One manufacturer - a complete range.
Impact strength
down to -60°C
Grade E with guaranteed Charpy viscosity at -60°C. DILLIMAX 690T — increased viscosity beyond EN 10025-6 and ASTM A514 requirements. Safety in arctic conditions.
Full metallurgical cycle
Dillinger controls 100% of the process — from the blast furnace to the marking of the finished sheet. 333+ years of experience in heavy plate.
Low carbon equivalent
Despite high strength, low CEV ensures reliable and economical welding without preheating (for thin thicknesses). Savings on technology.
UT-guarantee S1 E1
for the entire thickness
Ultrasonic testing according to EN 10160 (S1 E1) - beyond the requirements of the standard. Minimum levels of phosphorus and sulfur. Homogeneous structure even in super thick sheets.
DIPLAN and TL
— precise geometry
DIPLAN — guaranteed flatness of the surface over the entire sheet. DILLIMAX TL — ultra-tight thickness tolerances for extreme applications (crane booms).
DNV, ABS and Z-grade approvals
Certified for offshore applications (DNV, ABS). Z-grade according to EN 10164 - guaranteed properties in the thickness direction. Ideal for welded joints with large thicknesses.
333+
YEARS OF EXPERIENCE IN STEEL
World leader
in Q&T heavy plate
Dillinger, a leading European producer of heavy plate, has been setting standards in the production of high-strength fine-grained steels for decades. Q&T technology provides a unique combination of strength, toughness and weldability in heavy thicknesses.
Blast furnaces
Own production of cast iron from controlled raw materials
Steelmaking
Precise alloying of Cr, Ni, Mo for deep hardening
Vacuum degassing
Low P and S — minimal impurities, high purity
Continuous casting
Slabs with a homogeneous structure without segregations
TM-rolling
Thermomechanical rolling for fine grain structure
Quenching + tempering (Q&T)
Quenched and tempered — stable properties 500–1100 MPa
Full range of DILLIMAX brands
From 500 to 1100 MPa yield strength. B/T/E variants differ in guaranteed impact strength temperature: B → -20°C, T → -40°C, E → -60°C. The selection of the grade depends on your project - our engineers together with Dillinger experts will select the optimal solution.
* Variants B / T / E - guaranteed impact strength at -20°C / -40°C / -60°C respectively. DILLIMAX 690 E is available in thicknesses up to 200 mm.
DILLIMAX 500
500 MPa (72 ksi)
6–200 mm · S500Q / QL / QL1
Basic grade of the line. Q&T steel with excellent weldability. B/T/E variants for different operating temperatures.
🔹 Mechanical engineering, bridge construction
Open PDFDILLIMAX 550
550 MPa (80 ksi)
6–200 mm · S550Q / QL / QL1
Increased strength while maintaining excellent processability. T/E options - up to 150 mm thickness.
🔹 Load-bearing structures, crane construction
Open PDFDILLIMAX 690
690 MPa (100 ksi)
6–290 mm · S690Q / QL / QL1
HIT. Increased Charpy toughness beyond EN 10025-6 and ASTM A514. The most popular grade for heavy engineering.
🔹 Crane booms, excavators, bridges
Open PDFDILLIMAX 890
890 MPa (130 ksi)
6–160 mm · S890Q / QL / QL1
High strength for slimmer designs. Weight reduction with the same loads. B/T/E — down to -60°C.
🔹 Mobile cranes, special equipment
Open PDFDILLIMAX 965
960 MPa (140 ksi)
6–160 mm · S960Q / QL / QL1
Ultra-high strength. Allows radical weight reduction of mobile structures without loss of safety.
🔹 Highest mobile cranes, defense
Open PDFDILLIMAX 1100
1100 MPa (160 ksi)
8–40 mm · Own specification
The highest yield strength in the line. A unique solution for extreme loads at minimum weight.
🔹 Special designs, military-industrial complex
Open PDFDILLIMAX TL
up to 690 MPa
up to 150 mm · DH-E48-D
Ultra-narrow tolerances on thickness and geometry. Especially for the manufacture of mobile crane booms.
🔹 Crane booms, precision mechanics
Open PDFDILLIMAX Z-grade
all brands
thick sheets · EN 10164
Guaranteed properties in the thickness direction (Z15/Z25/Z35). Prevents lamellar cracking in welded joints.
🔹 Offshore platforms, heavy units
DILLIMAX 690 — the reference brand of the line
Data from the official Dillinger material passport. Q&T fine-grained structural steel with guaranteed properties exceeding EN 10025-6 and ASTM A514. The most popular grade for mechanical engineering, crane construction and bridge structures.
Mechanical properties
Chemical composition
Certification and quality control
Each DILLIMAX sheet is ultrasonically tested to EN 10160 (S1 E1) — exceeding the requirements of the standard. DNV and ABS approvals for offshore applications. Quality certificate 3.1 to EN 10204 for each batch — full traceability of the melt. On request — Z-grade to EN 10164.
Where strength decides everything
DILLIMAX is the material for projects where weight savings and reliability are critical. From mobile cranes and earthmoving equipment to offshore platforms and bridges. DNV/ABS approvals open up access to the most demanding industries.
HARD STEEL INDUSTRY
× DILLINGER
HARD STEEL INDUSTRY LLC is the official contact partner of Dillinger in Ukraine for the DIFENDER series. Direct deliveries of armored steel without intermediaries, with a full certification package and technical support from the factory.
CONTACT PERSON IN UKRAINE
Ukraine, 02099, Kyiv, Naberezhno-Lugova str., 8
Direct deliveries of high-strength steel to Ukraine
Ready to calculate DILLIMAX for your project?
Leave a request — a HARD STEEL INDUSTRY engineer will select the optimal grade, thickness, and cutting for your specifications. Calculation within 1 business day.
+38 067 180 07 70
Everything you need to know before ordering
DILLIMAX is a high-strength fine-grained steel manufactured using Q&T technology (quenched and tempered). The yield strength is 2–4 times higher than conventional structural steels (S355). This allows for a significant reduction in the weight of structures, savings on transportation and installation, with the same or higher safety. At the same time, DILLIMAX retains excellent weldability due to its low carbon equivalent.
The range includes 6 main grades: DILLIMAX 500, 550, 690, 890, 965 and 1100 (yield strength in MPa). Available thicknesses: 500/550 - 6–200 mm, 690 - 6–290 mm, 890/965 - 6–160 mm, 1100 - 8–40 mm. DILLIMAX TL (precise tolerances for crane booms) and Z-grade (with guaranteed properties in the thickness direction) are available separately.
These are different classes of guaranteed Charpy impact strength at low temperatures: B (Q) — guaranteed at -20°C, T (QL) — at -40°C, E (QL1) — at -60°C. The choice depends on the operating climate and project requirements. For Europe and Ukraine, the T-variant is typically used, for arctic conditions or increased safety — E.
Yes, this is one of the key advantages. Thanks to its low carbon equivalent (CEV), DILLIMAX can be welded reliably and economically with modern technologies. The factory provides detailed recommendations according to EN 1011-2: technology, preheating temperature (if necessary), electrode selection and welding sequence. For thin thicknesses, preheating is often not required.
DILLIMAX complies with EN 10025-6 (S500Q–S960QL1) and ASTM A514. Has DNV and ABS approvals for offshore applications. Each sheet is UT-tested to EN 10160 (S1 E1) — exceeding the requirements of the standard. Each batch is provided with a 3.1 certificate to EN 10204 with the results of chemical analysis and mechanical tests. On request — Z-grade to EN 10164 (Z15/Z25/Z35).
As an official Dillinger partner, HARD STEEL INDUSTRY provides direct deliveries. Some brands (in particular DILLIMAX 690) are available from stock. Production order terms depend on the brand, thickness, size and volume - we will provide accurate information upon calculation within 1 business day.
